Charakteristikos

Height

44 mm

Depth

118 mm

Width

200 mm

Power over Ethernet (PoE) power per port

30 W

Weight

600 g

Power source

AC

Switching capacity

12 Gbit/s

Cables included

AC

Jumbo Frames support

Yes

LED indicators

Activity Power Link

Full duplex

Yes

Networking standards

IEEE 802.3at IEEE 802.3 IEEE 802.3ab IEEE 802.3z IEEE 802.3af IEEE 802.3x IEEE 802.3u

Flow control support

Yes

Output Voltage

52 V

Power Connector

AC-in jack

Output Current

1.25 A

Housing material

Metal

Fanless

Yes

Power Over Ethernet (PoE)

Yes

Package Weight

900 g

Package Type

Box

Fiber type

Multi-mode

Product colour

Black

Guarantee

G024M

AC input voltage

100 - 240 V

Package width

245 mm

Package height

60 mm

Package depth

190 mm

Warnings

The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations. Do not open the case or try to repair it yourself.

Manual

Yes

Master (outer) case length

320 mm

Master (outer) case width

505 mm

Master (outer) case height

402 mm

Products per master (outer) case

20 pc(s)

Throughput

8.928 Mpps

Input current

1.25 A

Power supply included

Yes

Wall mountable

Yes

Operating temperature (T-T)

-20 - 50 C

Storage relative humidity (H-H)

5 - 90%

Storage temperature (T-T)

-40 - 85 C

Operating relative humidity (H-H)

10 - 90%

Plug and Play

Yes

Mean time between failures (MTBF)

100000 h

Ethernet LAN data rates

10,100,1000 Mbit/s

VLAN support

Yes

Total Power over Ethernet (PoE) budget

120 W

Rack mounting

Yes

MAC address table

2000 entries

Power over Ethernet (PoE) ports quantity

4

Combo SFP ports quantity

1

Installed SFP modules quantity

1

Half duplex

Yes

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Basic switching RJ-45 Ethernet ports quantity

5

Jumbo frames

9216

Store-and-forward

Yes

Copper ethernet cabling technology

100BASE-TX 10BASE-T 1000BASE-TX

Packet buffer memory

1 MB

Operating altitude

0 - 3048 m

Cable types supported

Cat7 Cat4 Cat6a Cat8 Cat6e Cat7e Cat5 Cat5e Cat3 Cat6 Cat8.1 Cat6+

Uplink ports quantity

1

Power over Ethernet plus (PoE+) ports quantity

1

Master (outer) case net weight

19 kg

Switching optical modules type

Gigabit Ethernet
