Charakteristikos

Height

44 mm

Depth

150 mm

Width

220 mm

Power over Ethernet (PoE) power per port

30 W

Power source

AC

Forwarding rate

1.48 Mpps

Cables included

AC

Jumbo Frames support

Yes

LED indicators

Link Power PoE Activity

Full duplex

Yes

Networking standards

IEEE 802.3x IEEE 802.3af IEEE 802.3az IEEE 802.3at

Flow control support

Yes

Power Connector

AC-in jack

Housing material

Metal

Fanless

Yes

Power Over Ethernet (PoE)

Yes

Surge protection

Yes

Package Type

Box

Product colour

Black

Guarantee

G024M

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Power supply included

Yes

Operating temperature (T-T)

0 - 40 C

Quick start guide

Yes

Storage relative humidity (H-H)

5 - 90%

Storage temperature (T-T)

-40 - 70 C

Operating relative humidity (H-H)

10 - 90%

Plug and Play

Yes

Bandwidth

2 Gbit/s

Mean time between failures (MTBF)

50000 h

Ethernet LAN data rates

10,100 Mbit/s

VLAN support

Yes

Total Power over Ethernet (PoE) budget

120 W

MAC address table

8000 entries

Power over Ethernet (PoE) ports quantity

8

Half duplex

Yes

Basic switching RJ-45 Ethernet ports type

Fast Ethernet (10/100)

Basic switching RJ-45 Ethernet ports quantity

8

Jumbo frames

1528

Store-and-forward

Yes

Copper ethernet cabling technology

100BASE-TX 10BASE-T

Packet buffer memory

0.25 MB

Cable types supported

Cat5 Cat5e Cat3 Cat4

Uplink ports quantity

2

Power over Ethernet plus (PoE+) ports quantity

2

Surge protection voltage

4 kV
