Cooler included

No

Thermal Design Power (TDP)

65 W

Processor family

Intel Xeon E

Processor manufacturer

Intel

Processor model

E-2324G

Processor Socket

LGA 1200 (Socket H5)

Guarantee

G012M

Warnings

Do not disassemble the processor or attempt to repair it yourself. Avoid direct contact with water and high humidity. The product should be used in accordance with the manufacturer's instructions to avoid damage.

Harmonized System (HS) code

85423119

Commodity Classification Automated Tracking System (CCATS)

G167599

Box

No

Launch date

Q3'21

Processor cache type

Smart Cache

Processor threads

4

Processor operating modes

64-bit

Processor cache

8 MB

Component for

Server/workstation

Processor cores

4

Processor lithography

14 nm

Processor base frequency

3.1 GHz

Discrete graphics card

No

On-board graphics card

Yes

On-board graphics card base frequency

350 MHz

Discrete graphics card model

Not available

On-board graphics card model

Intel UHD Graphics P750

Market segment

Server

PCI Express slots version

4.0

Memory types supported by processor

DDR4-SDRAM

Memory channels

Dual-channel

Processor boost frequency

4.6 GHz

Maximum number of PCI Express lanes

20

ECC

Yes

Maximum internal memory supported by processor

128 GB

Status

Launched

On-board graphics card OpenGL version

4.5

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

60 Hz

On-board graphics card dynamic frequency (max)

1300 MHz

On-board graphics card refresh rate at maximum resolution (HDMI)

60 Hz

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

Number of execution units

32

Scalability

1S

Thermal Monitoring Technologies

Yes

PCI Express configurations

1x16+1x4 2x8+1x4 1x8+3x4

Idle States

Yes

CPU configuration (max)

1

Supported instruction sets

AVX 2.0 SSE4.1 SSE4.2 AVX-512

Execute Disable Bit

Yes

Export Control Classification Number (ECCN)

5A992CN3

Tjunction

100 C

Processor package size

37.5 x 37.5 mm

Intel Boot Guard

Yes

Intel Hyper Threading Technology (Intel HT Technology)

No

Intel Clear Video HD Technology (Intel CVT HD)

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel Quick Sync Video Technology

Yes

Intel Secure Key

Yes

Intel AES New Instructions (Intel AES-NI)

Yes

Intel Turbo Boost Technology

2.0

Enhanced Intel SpeedStep Technology

Yes

Intel 64

Yes

Intel OS Guard

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Virtualization Technology (VT-x)

Yes

Maximum internal memory

128 GB

Supported memory types

DDR4-SDRAM

System bus rate

8 GT/s

Processor ARK ID

212255

On-board graphics card 4K support

Yes

Maximum on-board graphics card memory

64 GB

Intel Clear Video Technology

Yes

Intel InTru 3D Technology

Yes

Intel Trusted Execution Technology

Yes

Intel Turbo Boost Technology 2.0 frequency

4.6 GHz

Intel Transactional Synchronization Extensions

No

Intel vPro Platform Eligibility

Yes

Intel Software Guard Extensions (Intel SGX)

Yes

Servicing status

Baseline Servicing

Maximum Enclave Size Support for Intel SGX

0.5 GB

Intel Optane DC Persistent Memory Supported

No

Intel Memory Protection Extensions (Intel MPX)

Yes
